Zinc Alloy Sand Casting Parts
Product Name:Zinc alloy sand casting parts
Material:Zinc Alloy
Torrance:±0.1mm
Finish:Electroplating
Description:
| Product name: | Zinc alloy sand casting parts |
| Material: | Zinc Alloy |
| Torrance: |
±0.1mm |
| Finish: | Electroplating |
| Process: |
Electroplating,Sand casting,powder coating |
| Application: | Automotive |
| Design: | Various type of 2D or 3D drawings are acceptable, such as JPG, PDF, DWG, DXF, IGS, STP, X_T, SLDPRT etc. |
| Standards: | AISI, ATSM, UNI, BS, DIN, JIS, GB etc. |
| Delivery time: | 35 days for samples and 30 days for production. |
| Package: | Bubble bag+box+pallet |
| Service: | OEM/ODM |
| Advantage: | 1. High quality material products 2. Fine casting technique 3. Accurate product dimensions 4. Nice quality with good surface |
Our zinc alloy sand casting parts deliver exceptional value through superior craftsmanship and material performance. Manufactured using high-purity Zamak 3 (ZnAl4) alloy and traditional sand casting techniques, these components offer an optimal balance of strength, dimensional accuracy, and cost-efficiency for industrial applications.
Key Advantages:
Material Excellence
Certified Zamak 3 alloy (Al 3.9-4.3%, Mg 0.03-0.06%)
Excellent fluidity for complex geometries
Natural corrosion resistance & EMI shielding properties
Precision Sand Casting
Tolerance: ±0.25mm per 25mm (ISO 8062 CT8-10)
Surface finish: Ra 12.5μm (as-cast), improvable to Ra 3.2μm
Max. part weight: 50kg | Min. wall thickness: 3mm
Performance Features
Tensile strength: 280-330 MPa
Impact resistance: 45 J/cm²
Service temperature: -40°C to 120°C
Typical Applications:
Industrial Machinery: Gears, housings, pulleys
Agricultural Equipment: Wear-resistant components
Automotive: Non-engine brackets, lever arms
Architectural Hardware: Decorative fittings
Value-Added Services:
• Secondary machining (milling, drilling, tapping)
• Surface finishing (powder coating, electroplating, polishing)
• Full material certification (EN 12844 compliant)
• Custom pattern development
Factory Pictures:
